Features:
1.Usage imported chips 3030smd as the source of light, with a unique lighting design made of multiple
chips integrated in a single module. Based on a selection of excellent imported semiconductor chips, it has high thermal conductivity, low luminous decay, pure colors, no heavy shade etc.
2.Unique cooling body design combined with perfect driver box to help heat conduction and diffusion, this reduces efficiently the temperature of the lamp body and so provides to the LED and its power supply a longer lifespan.
3.Sandblasting process and anodic oxidation surface treatment applied to the cooling body providing to the lamp an elegant and compact overall structure.
4.Environmentally friendly, it contains no lead, no mercury or any other elements that may harm the environment.
5.High color rendering level that shows true colors of things to people. Several colors are also available to meet specific requirements, delivering different kinds of atmosphere, reducing the depressive mood from traditional lamps with uneven color temperatures, improving work efficiency with better visual comfort.
6.Advanced constant current and voltage control techniques, wide power adaptation coverage to fit all countries specificities, management of electrical unstable factors with a power grid and noise pollution with ballast, high lighting stability delivered avoiding unnecessary additional work effort for the eyes and thus preventing from eyestrain.
7.Excellent decoration integration, unique surface treatment technology, modern design, easy installation, simple dismount, wide range of applications.
No
Parameter
01
Szie
595*595*12mm
02
Input Voltage
AC 100-240V
03
Working Voltage
≤38V
04
Power
□36W □48W □54W □72W
05
Luminous
□36W 3400lm±5% □48W 4320lm±5%
□54W 4860lm±5% □72W 6480lm±5%
06
Power Efficiency
□36W 70-80 lm/w □48W 90lm/w±5%
□54W 90lm/w±5% □72W 90lm/w±5%
07
Color
Warm/Natural/Cool White
08
Color Temp
□WW / Warm White 2800-3200K □NW / Natural White 4000-4500K
09
CRI
≥80Ra
10
LED Qty
2835
□36W 192 PCS □48W 240 PCS
□54W 288 PCS □72W 384 PCS
11
LED Type
□HONGLITRONIC 2835 □LumenMax 2835
12
Life Span
50000 Hours
13
Operating Temp
-20ºC — 50ºC
14
Storage Temp
-20ºC — 60ºC
15
Net Weight
3.9 Kg
16
Gross Weight
4.5 Kg
17
IP
IP 40
□W / White 5000-5500K □CW / Cool White 6000-6500K
