led street light(PL-LD-061-2)

Model

PL-LD-061

PL-LD-061

PL-LD-061

PL-LD-061

Input Voltage

DC12V/24V , 100-305 V AC

Power

30W 40W 50W 60W

70W 80W 90W 100W

120W 150W

180W 200W

Size(mm)

558*200*115mm

612*233*115mm

675*260*115mm

775*320*120mm

Net weight

3.50kg

5.00kg

6.40KG

9.00KG

1PCS/CTN,ctn size(cm)

61*26*13.5cm

66*28*13.5cm

71*29*13.5cm

78*35*13.5cm

LED chip

Lumileds 3030SMD

CRI

Ra>70/80

Power Factor

>0.95

Light efficiency

150LM/W±5%

Beam angle

TYPEII /TYPEIII

LED driver brand

HONTEK ,Inventronics , Meanwell driver ELG series

Surge protection

4-6KV/10KV/20KV as customers' rerquirement

lamppost diameter

48mm/52mm/60mm

Waterproof and IK

IP66&IK08

Housing material

Die-cast aluminum +tempered glass

Storage temperature

-40℃~85℃ 10%~90% H.R

Work temperature

-40℃~50℃  20%~90% H.R

Lifespan

(L80B10) 100000 hours

warranty

5 -8years
